DTV Installation
Connect the DTV antenna to the ANTENNA IN jack on the rear panel as described below.
And connect the ANTENNA OUT jack on the rear panel to the ANTENNA IN jack on your TV using RF cable.
or or
TV
Outdoor
Aerial
TV
Indoor
Aerial
Wall
Jack
or or
If you are using an indoor antenna, use one with a signal amplifier rated at DC 5V, 100mA and set “Antenna Feed 5V”
option to [ON] on the setup menu. (see page 24)
Caution
The [Antenna Feed 5V] option must be set to [Off] when your indoor antenna is supplied the power from the
mains. If you set [Antenna Feed 5V] option to [On] for the indoor antenna which is supplied power from the
mains, it may cause serious defect to this recorder.
DTV
